The Model 735 mono blocks represent the pinnacle of our class AB amplifier design technology. Based upon the evolutionary legacy of the 625/725 amplifier series, the 735 amplifier incorporates an amorphous core input transformer and other innovative design principles allowing the listener to fully experience the heart and soul of the musical composition, ensuring a lifetime of musical enjoyment.
MACHINED ALUMINUM CHASSIS
Precision-machined chassis with integrated heatsinks, milled from a solid block of aircraft grade 6061-T6 aluminum, provides exceptional thermal heat transfer/dissipation, RFI/EMI shielding, and resonance control.
CERAMIC CIRCUIT BOARDS
All audio circuits are implemented on mil-spec, multi-layer, low dielectric constant, Rogers™ ultra-rigid ceramic circuit board substrate for extremely low energy retention and absorption. Large low impedance ground plane areas for extended internal star-grounding.
Inherent cancellation effects of balanced topology implemented throughout all power and input/output circuits ensures greatly reduced distortion and noise under dynamic signal conditions.
HIGH CURRENT COPPER BUS-BARS
High current, dual polarity, ultra low impedance copper bus-bars distribute both power supply input current and signal output current, virtually eliminating intra-circuit EMI signal contamination, greatly reducing internal wiring, while increasing circuit board rigidity.
HIGH-PRECISION SURFACE MOUNT COMPONENTS
Extensive use of Lead (Pb)-free, low temperature coefficient, active and passive surface-mount components results in significantly smaller loop areas, reduced circuit capacitance and inductance, and introduces less noise than conventional leaded components.
TRANSFORMER-COUPLING AND ISOLATION
Transformer coupled input circuitry provides universal component compatibility and virtually eliminate ground loop noise and RFI/EMI. Transformer coupling ensures identical amplifier overall gain when using unbalanced input adapters.
POWER FACTOR CORRECTION
Power Factor Correction (PFC) in the power supply reduces AC line harmonic noise pollution and increases AC line power utilization to 99%.
HIGH-EFFICIENCY SWITCH-MODE POWER SUPPLY
Highly efficient, compact, light weight, 1500 watt DC switch-mode power supply provides optimum voltage regulation for all circuits and operating conditions, and allows for quiet operation over a wide range of AC mains power sources.
PARALLEL BINDING POSTS
Dual CE approved speaker output terminals require no tools for secure, low resistance connections, and allow for easy bi-wiring applications.
FLEXIBLE 20 AMP AC POWER
20 amp AC power inlet accepts a wide variety of after-market high-performance power cables.
FRONT PANEL STANDBY BUTTON
Illuminated front panel push-button switches the amplifier into standby mode (< 1 watt consumption).
REAR PANEL REMOTE JACK
12V 3.5mm jack on rear panel permits amplifier power on/standby switching in remote and home theater applications.
Removable 3-point self-leveling Delron chassis supports provide high frequency mechanical noise isolation.
|330 watts @ 8 ohms / 650 watts @ 4 ohms|
|5 Hz – 90 kHz, – 3 dB|
|95 dB, ref. 1.0 watt @ 8 ohm load|
|Output Noise||<55 µv, 20 Hz – 20 kHz, unweighted|
|Input Impedance||40k ohms|
|THD + Noise||<0.001% from 2.0 kHz – 20 kHz, gradually increasing below 2khz due to amorphous core input transformer characteristics|
|Damping Factor||>500, 20 Hz – 20 kHz|
|Overall Gain / Bal. or Unbal.||26 dB|
|Common Mode Rejection Ratio||> 90 dB, 20 Hz – 20 kHz|
|Absolute Phase Non-inverting||Pin 2 Positive|
|Outputs||2 pair parallel binding posts|
|Power Consumption Idle||85 watts/VA, power factor corrected at all power levels|
|Power Consumption Standby||0.3 watt|
|Amplifier Weight||54 lbs. / 24.5 kg (each)|
|Amplifier Shipping Weight||64 lbs. / 29 kg (each)|
|Amplifier Dimensions (h/w/d)||5.75” x 15.5” x 16.25” / 146mm x 394mm x 413mm|
