SA10
In any amplifier, the signal path is at the mercy of anything that creates noise within the unit. Thus, we spare no expense in using only the most high-quality components, even if it means the cost of our power supplies overtaking that of everything else.
The result, of course, is worth every penny.
A singer’s sharp intake of breath before hitting the chorus, a guitarist’s fingers sliding against the strings – it’s those seemingly minor details that can bring music to life. Fish out one of your all-time favourite albums and play it through a Bluetooth speaker, and guess what? Its sounds like a Bluetooth speaker. Play it through the SA10, and it’s as close to hearing the artist’s performance as you’re likely to get. There’s always joy in digging out an old recording you haven’t heard in years. With the HDA range, it’ll feel like hearing it forthe first time.
PRODUCT DETAILS
- Extremely efficient class A/B amplification
- 50W of power per channel
- 5 analogue inputs including phono
- 3 digital inputs
- 32-bit DAC,Sabre ESS9016K2M
- Full I/P control
- Total harmonic distortion + noise = 0.003%
Specifications
| Continue vermogensuitgang (0,5% THD), per kanaal | ||
| Beide kanalen, 8 Ω, 20 Hz-20 kHz | 50W | |
| Beide kanalen, 4 Ω, op 1 kHz | 85W | |
| Harmonische vervorming, 80% vermogen, 8 Ω op 1 kHz | 0,003% | |
| Analoge ingangen | ||
| Phono (MM) cartridge: | ||
| Ingangsgevoeligheid op 1 kHz | 5mV | |
| Ingangsimpedantie | 47 kΩ + 100 pF | |
| Frequentiebereik (zie RIAA kromme) | 20Hz – 20kHz ± 1dB | |
| Signaal/ruisverhouding (A-wtd) 50W, ref. 5mV invoer | 80 dB | |
| Overbelastingmarge, ref. 5mV op 1kHz | 21dB | |
| Lijningangen: | ||
| Nominale gevoeligheid | 1V | |
| Ingangsimpedantie | 10 kΩ | |
| Maximale ingang | 6Vrms | |
| Frequentiebereik | 20Hz – 20kHz ± 0,2dB | |
| Signaal/ruisverhouding (A-wtd) 50W, ref. 1V invoer | 106 dB | |
| Digitale ingangen | ||
| DAC | ESS9016K2M | |
| Frequentiebereik | 20Hz - 20kHz ± 0,05dB | |
| Totale harmonische vervorming + ruis | 0,0007% | |
| Signaal/ruisverhouding (A-wtd) | 115dB | |
| Ondersteunde samplesnelheden | Optisch | Coaxiaal |
| 32kHz, 44,1kHz, 48kHz, 88,2kHz, 96kHz | 32kHz, 44,1kHz, 48kHz, 88,2kHz, 96kHz, 176,4kHz, 192kHz | |
| Bitdiepte | 16-bit – 24-bit | |
| Voorversterkeruitgang | ||
| Nominaal uitgangsniveau | 630mV | |
| Uitgangsimpedantie | 230 Ω | |
| Hoofdtelefoonuitgang | ||
| Maximaal uitgangsniveau in 600 Ω | 5Vrms | |
| Uitgangsimpedantie | 1 Ω | |
| Belastingbereik | 16Ω – 2kΩ | |
| Algemeen | ||
| Netspanning | 110–120V of 220–240V, 50–60Hz | |
| Maximaal stroomverbruik | 350W | |
| Afmetingen B x H x D (inclusief voetstukken, bedieningsknop en luidsprekerklemmen) | 433x87x310mm | |
| Gewicht (netto) | 8.4kg | |
| Gewicht (bruto) | 10.7kg | |
