New soft dome HF unit with precision alloy ATC wave guide.
Liên hệ giá tốt nhất
SCM 7
Features
- New soft dome HF unit with precision alloy ATC wave guide.
- 125mm ATC mid/bass unit with integral soft dome.
- In-house, hand-wound precision flat wire coil.
- 3Kg optimised motor assembly.
- Massive optimised motor assembly.
- Flat impedance curve allowing easy load for amplifiers.
- 6 year warranty.
- Veneer. Cherry / Black Ash
Drivers :
HF 25mm Neodymium, Mid/LF 125mm
Matched Response :
±0.5dB
Frequency Response (-6dB) :
60Hz-22kHz
Dispersion :
±80° Coherent Horizontal, ±10° Coherent Vertical
Sensitivity :
84dB @ 1W @ 1metre
Max SPL :
103dB
Recommended Power Amplifier :
50 to 300 Watts
Nominal Impedance :
8 Ohm
Crossover Frequency :
2.5kHz
Connectors :
Binding Posts/4mm Plugs, bi-wire
Cabinet Dimensions (HxWxD) :
300x160x230mm
Weight :
7kg
